Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding

I'm Online Chat Now

Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding

Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding

Large Image :  Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding

Product Details:
Place of Origin: Shanghai, China
Brand Name: upasschina
Model Number: UF508 Anti-Aging Film
Payment & Shipping Terms:
Price: $0.17 - $0.69/rolls

Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding

Description
Plastic Modling Type: Blow Molding Product Name: UF508 Anti-Aging Film
MOQ: 5000 Square Meter Type Science And Technology: Casting/Blow Molding
Size: 100*55*55cm/roll
Highlight:

Anti Aging Film

,

Plastic Molding Anti Aging Film

,

UF508 Anti Aging Film

Products Description
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 0


Anti-Aging Film(UF508)
Material: PET / fluorine film weathering film Type: Surface film Application: Polymer waterproofing membrane, butyl adhesive tape surface material Performance: Weather resistance Hardness: Hard Processing / production process: Laminated Transparency: Opaque Attribute: Color: white Thickness: 0.08-0.15mm Width: 900-1100mm Sleeve I.D.: 76mm Packaging: Bubble membrane + tray Product introduction: 1.According to the requirements of general specifications for waterproofing for construction and municipal engineering: The working period of waterproof design for roofing engineering should not be less than 25 years; 2.Excellent anti-aging, ultraviolet resistance, weather resistance, acid and alkali resistance, chemical corrosion resistance, high temperature and humid heat resistance, extreme cold resistance, reflectivity up to 85%, weather resistance life of more than 25 years, can replace the traditional exposed waterproof materials and waterproof coil film; 3.The structure is specially designed for the weather resistant industry, and it is cost-effective;
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 1
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 2
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 3
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 4
Application scenarios:
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 5
Weather resistant waterproofing membrane
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 6
Weather resistant adhesive tape
Performance index



Test item
Test method
Value
Remark
Thickness
GB/T6672-2001
/
0.12mm
Width
GB/T6673-2001
/
As per requirements
Max. tensile strength
GB/T 328.9-2007
MD:770N
TD:762N
Rectangle Specimen-Width: 25mm, Stretching speed: 100mm/min.,
Fixture gauge length: 100mm
Max.F
N/50mm
≥200
≥300
Elongation@Break
%
≥50
≥50
Elongation @ break
%
≥500
≥500
Peeling force
GB/T 529-2008
MD:23N
TD:21N
Stretching speed:250mm/min
Surface tension
GB/T14216
≧42dyn/cm
Dyne pen test
Rate of dimensional changes
GB/T 35467-2017
MD:0%
TD:0%
90℃&24h
MVTR

≦70 g/m2.24h (20um)
38℃+100%RH
Electrolytic sensor method
Weather resistance

Artificial climate aging 3000h (appearance)
No bubble,
No cracks,
No layering defect,
No Adhesion and No hole
GB/T 16422.2-2014
GB/T 12952-2011
Method A: Exposure cycle 2, temperature 23℃±2℃, relative humidity (50±5)%
Recommend Products
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 7
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 8
Company Profile
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 9
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 10
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 11
Product packaging
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 12
FAQ
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 13
Q1: Are you trading company or manufacturer ?
A1: We are manufacturer.
Q2: Do you provide samples ? is it free or extra ?
A2: Yes, we could offer A4 sample for free charge but if you need in roll,we can offer 100-200m/roll for free, but shipping cost need you to paid.
Q3: How long is your delivery time?
A3: Depends on your quantity. Generally it is about 30 days for 20GP container.
Q4: How to pay for your goods?
A4: By L/C, by T/T (30% deposit before production, 70% balance before loading).
Weather Resistant Adhesive Tape Laminated UF508 Anti-Aging Film for Plastic Molding 14
