Surface Material PVDF Laminated With PET Anti Corrosion Film

Surface Material PVDF Laminated With PET Anti Corrosion Film
Surface Material PVDF Laminated With PET Anti Corrosion Film Surface Material PVDF Laminated With PET Anti Corrosion Film Surface Material PVDF Laminated With PET Anti Corrosion Film

Large Image :  Surface Material PVDF Laminated With PET Anti Corrosion Film

Product Details:
Place of Origin: China
Brand Name: Upass
Certification: CE, ROHS
Model Number: Laminated Film
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Bubble Wrap & Wooden Pallet
Delivery Time: 15days
Payment Terms: T/T,L/C
Supply Ability: 200,000㎡~300,000㎡

Surface Material PVDF Laminated With PET Anti Corrosion Film

Description
Product Name: Surface Material PVDF Laminated With PET Anti Corrosion Film Material: PVDF Film+ PET Film
Production Process: Laminated Performance: Weather Resistance 25 Years
Thickness: 0.08/0.1mm Width: 100-1000mm
Color: White Application: Butyl Tapes, Waterproofing Membranes
Printing: Can Be Customizable Resistance Years: More Than 25 Years
High Light:

PVDF Laminated Film

,

Surface Material PVDF Film

,

Anti Corrosion PET Film

           Surface Material PVDF Laminated with PET Anti Corrosion Film​



Description:



It used as surface material, PET film laminated with fluorine film(PVDF), make the film high strength and aging resistance. It is specially designed for waterproofing industry, which shall substitute conventional exposed waterproofing material including the film for waterproofing membrane. It also has cost effectiveness , and lasts over 25years of weather resistance.





Parameter:



Detection Item Detection Method Detection Value Remark
Thickness UF508 GB/T6672-2001 0.075mm/0.125mm /
Width GB/T6673-2001 / According to customer needs
Max force UF508 GB/T 328.9-2007 MD:770N Rectangular spline, spline width 25mm, stretching rate: 100mm / min, fixture gauge distance: 100mm
TD:762N
Elongation at Break UF508   MD:79%
TD:99%
Tensile Strength UF508 GB/T 529-2008 MD:23N Stretching speed:250mm/min
TD:21N
Surface Tension GB/T14216 ≧42dyn/cm Dyne Pen Test
Dimensional change rate UF508 GB/T 35467-2017 MD:0% 90℃&24h
TD:0%
Water vapor transmission rate GB/T 21529 ≦70 g/m2.24h (20um) 38℃+100%RH
Electrolytic sensor method
Flammability grade UL94 VTM-0 White weathering film
Aging test PCT96 / Yellowing index △b≤2.0, Temperature 121 ℃, humidity 100%, air pressure 2atm, time 48h
  UV300KWh IEC61215   The temperature of the sample is 60 ± 5 ℃, and the total exposure is 120KWh • m2, of which UVB accounts for 3% -10%.
  DH2000h IEC61215   Temperature 85 ℃, humidity 85% R.H., 2000h
  TC400 IEC61215   Temperature -40 ℃ ~ 85 ℃, 6h / cycle, 400cycle



Surface Material PVDF Laminated With PET Anti Corrosion Film 0



Surface Material PVDF Laminated With PET Anti Corrosion Film 1
