Product Details:
Place of Origin: CHINA
Brand Name: UPASS
Certification: ISO
Payment & Shipping Terms:
Minimum Order Quantity: 30000 SQM
Packaging Details: Bubble or Film Wrap
Delivery Time: 7-15 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 200 Tons/Month

UV Curing Silicone Coated Release Liner HDPE PE Liner

Description
Product Name: HDPE Liner PE Liner Release Liner Silicone Coated Release Liner Material: HDPE, Polypropylene(PP), Polyolefin
Type: Removable Film Application: Waterproof Membranes And Tapes
Performance: Temperature Resistance:170 ℃ Curing Type: UV Curing
Silicone: Solvent Less Silicon Transmission: Less Than 10%
Highlight:

Silicone Coated Release PE Liner

,

UV Curing Silicone Coated HDPE Liner

,

Waterproof Membranes Silicone Coated Release Liner

Description:

Release Liner or Release Film is siliconized on PE, PET, PP or other type plastic films or papers, that enables to possess release effectiveness. It is usually used as the protective film of self-adhesive products, and directly peeled off from the self-adhesive products when used.



YK hydrophilic PE Release Film is an upgraded version of ordinary hydrophilic Release Film. YK hydrophilic PE Release Film overcomes the shortcomings of ordinary hydrophilic PE Release Film, such as low temperature resistance and low Subsequent adhesion rate. High temperature resistance, high residual connection and low silicon rotation; At the same time, in the competition with PET release film, it can solve the wrinkles formed by the use of PET release film coiled material on the surface of the coiled material after rolling, avoid the leakage caused by the possible hollowing, and solve the problem that the PET release film is difficult to tear in summer. At the same time, YK hydrophilic PE Subsequent adhesion rate is a polyolefin material, which can be recycled and reused. It can solve the problem that the PET isolation film cannot be recycled and difficult to deal with after use, which is more environmentally friendly.



Parameter:

Name YK hydrophilic PE Release Film Specification 0.03mm*1050mm
Testing Method   Date 2022.9.15
NO. Testing Item Factory Requirement Testing Result Conclusion
1 Appearance No bubble , no broken Qualified Qualified
2

Specification

(mm)

Width 1050±5mm 1052 Qualified
    Thickness 0.03±0.005mm 0.031 Qualified
3

Max.F

(N/50mm)

TD ≥30 102 Qualified
    MD ≥40 114 Qualified
4

Elongation@Break

(%)

TD ≥500 864 Qualified
    MD ≥500 726 Qualified
5 Tensile Strength(MPa) TD ≥20 28 Qualified
    MD ≥30 32 Qualified
6

Release Force

(N/25mm)

≤0.025 Qualified

7 Subsequent Adhesion
(%)
≥85 87 Qualified



Applications:



Release Film For Self-adhesive Waterproof Membranes:



UV Curing Silicone Coated Release Liner HDPE PE Liner 0



UV Curing Silicone Coated Release Liner HDPE PE Liner 1



Release Film For Self-adhesive Tapes:





silicone coated PE release film for self-adhesive waterproofing membranes
