Temperature Resistance UV Type HBF Silicone Coated Release Liner

Temperature Resistance UV Type HBF Silicone Coated Release Liner
Temperature Resistance UV Type HBF Silicone Coated Release Liner Temperature Resistance UV Type HBF Silicone Coated Release Liner Temperature Resistance UV Type HBF Silicone Coated Release Liner Temperature Resistance UV Type HBF Silicone Coated Release Liner Temperature Resistance UV Type HBF Silicone Coated Release Liner

Large Image :  Temperature Resistance UV Type HBF Silicone Coated Release Liner

Product Details:
Place of Origin: China
Brand Name: UPASS
Certification: ISO9001
Model Number: HBF
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wooden Pallet
Delivery Time: Negotiable
Payment Terms: TT/LC
Supply Ability: 200 Tons/Month

Temperature Resistance UV Type HBF Silicone Coated Release Liner

Description
Product Name: Temperature Resistance UV Type HBF Silicone Coated Release Liner Material: Polypropylene (PP)
Thickness: 0.035-0.15mm Width: 100-1500mm
Application: Used For Waterproofing Membranes, Adhesive Tapes,etc. Color: Black, Grey, White, Blue, Green, Etc.
Performance: One Or Two Side Silicone Coated Process: Seven-layers Blowing
Temperature Resistance: 150-180℃ Coating Type: UV Or Thermal Curing
High Light:

Temperature Resistance Silicone Release Liner

,

UV Type Silicone Release Liner

,

HBF Silicone Release Liner

     Temperature Resistance UV Type HBF Silicone Coated Release Liner

Description:

Silicone coated release liner refers to the plastic film or craft/GLASSINE paper which coated

silicon on single or double sides of the surface.



HBF Silicone Coated Release Liner is PP plastic film as carrier, silicon coated on one side or

both side by UV or Thermal curing type depends on the applications.



The performance is High Temperature Resistance, can does 150-180℃.

It is the testing of 80 degrees after 6 hours bellow:

1. Picture of before testing:

Temperature Resistance UV Type HBF Silicone Coated Release Liner 0



Picture of after tested:

Temperature Resistance UV Type HBF Silicone Coated Release Liner 1



From above two pictures, there is no yellowing, no color change after tested but a little

bit shrinkage.

Free samples will be offered if you want to testing.





Parameter:



Products Name High Temperature Resistance HBF Silicone Coated Release Liner Spec. 0.04mm*1040
Detection Methed Q/TPXP 1-2013 Date 2021.11.13
NO. Item Factory Requirement Detection Value Individual Determination
1 Appearance No bubbles, no stains, no damage, no impurities Qualified Qualified
2 Spec. Width 1040±10mm 1041 Qualified
    Thickness 0.04±0.005mm 0.041 Qualified
3

Max.F

(N/50mm)

TD

(CD)

≥30 68 Qualified
    MD ≥30 72 Qualified
4

Elongation

(%)

TD

(CD)

≥150 532 Qualified
    MD ≥200 358 Qualified
5 Tensile Strength

TD

(CD)

≥16 23 Qualified
    MD ≥18 36 Qualified
6

Release Force

(N/25mm)

3-5g, 5-10g 8.1 Qualified
7 Subsequent Adhesion
(%)
≥90 93 Qualified



Applications:

♦ Used for self-adhesive waterproof membranes and other self-adhesive products
♦ Used for hot-melt glue tapes/products
♦ Used for butyl adhesive tapes/products

Self-Adhesive Waterproofing Membranes:

Temperature Resistance UV Type HBF Silicone Coated Release Liner 2

Butyl Tapes:

Temperature Resistance UV Type HBF Silicone Coated Release Liner 3





About Upass:



Temperature Resistance UV Type HBF Silicone Coated Release Liner 4



Temperature Resistance UV Type HBF Silicone Coated Release Liner 5



UPASS, founded in 2008, is headquartered in New Materials Industrial Park, Qingpu District, Shanghai, and has two production bases in Jiangsu and Hunan province in China. UPASS adopts European professional film manufacturing equipment and technology, mainly provides SDM strong cross film, various functional RELEASE FILMS, PE FILMS (release / self-adhesive / hydrophilic / flame-retardant / skid-resistance / tear-lined / weather resistance), PET FILMS (release / self-adhesive / non-silicone release / anti-static), PP FILMS (release / thermal lamination), other functional laminated films, etc. The related products are widely used in roof / flashing / underlayment, air-barrier products, labels, medical products, electronic packaging, decoration, electronic optics and other fields. Especially in the field of building waterproofing in China, UPASS occupies an important position.
UPASS will spare no effort in strengthening and improving the production, sales networks, service system to return the trust and support of customers, and look forward to cooperating with you in the near future.
