Product Details:
|
| Features: | High Temperature Resistance | Product Name: | Waterproof Application PET Silicone Coated PET Release Liner |
|---|---|---|---|
| Material: | PET | Thickness: | 0.012-0.15mm |
| Width: | 100-2000mm | Application: | Used For Waterproofing Membranes, Adhesive Tapes,etc. |
| Color: | Transparent, White, Gray, Etc. | Performance: | Single Or Double Side Silicone Coated |
| Process: | Extrusion Casting | Soft: | Hard Than HDPE Film |
| High Light: | 0.012mm Silicone Coated Release Liner,12 Micron Silicone Coated Release Liner,0.012mm PET release film |
||
PET release film is also called PET silicone oil film. A layer of silicone oil is applied on the
surface of the PET film to reduce the adhesion of the PET film surface and achieve the
release effect.
Can be divided into single-sided release film and double-sided release film.
According to the release force, it can be divided into a light release film, a medium release
film, and a heavy release film.
Our company is equipped with a quick slitting machine that can be divided and sliced
according to customer specifications.
Features:
| ► High temperature resistance, up to 180℃ ► Easy peel off when remove the release film ► High residual adhesiveness rate(≥90%) to prevent the influence of silicon transfer on products ► Make products' surface more flat |
Applications:
| ♦ Used for self-adhesive waterproof membranes and other waterproof materials, adhesive tapes ♦ Used for cables production, packaging materials ♦ Used for cast materials, electronic applications, ceramic capacitors, window materials. printing, electronic, advertisements |
Phameter:
| Products Name | PET release film | Spec. | 0.023mm*1000mm | ||
| Detection Methed | Q/TPXP 1-2013 | Date | 2020.9.26 | ||
| NO. | Item | Factory Requirement | Detection Value | Individual Determination | |
| 1 | Appearance | No bubbles, no stains, no damage, no impurities | Qualified | Qualified | |
| 2 | Spec. | Width | 1000±5mm | 1001 | Qualified |
| Thickness | 0.023±0.005mm | 0.023 | Qualified | ||
| 3 |
Max.F (N/50mm) |
TD (CD) |
≥150 | 192 | Qualified |
| MD | ≥150 | 156 | Qualified | ||
| 4 |
Elongation (%) |
TD (CD) |
≥40 | 87 | Qualified |
| MD | ≥40 | 56 | Qualified | ||
| 5 | Tensile Strength(Mpa) |
TD (CD) |
≥30 | 124 | Qualified |
| MD | ≥30 | 108 | Qualified | ||
| 6 | Subsequent Adhesion | % | ≥90 | 92 | Qualified |
| Detection | Qualified | ||||
FAQ:
|
Q1: Are you trading company or manufacturer ? A1: We are manufacturer.
Q2: Do you provide samples ? is it free or extra ? A2: Yes, we could offer A4 sample for free charge but if you need in roll, we can offer 100-200m/roll for free, but shipping cost need you to paid.
Q3: How long is your delivery time? A3: Depends on your quantity. Generally it is about 30 days for 20GP container.
Q4: How to pay for your goods? A4: By L/C, by T/T (30% deposit before production, 70% balance before loading). |
About Upass:
| Upass, founded in 2008, now as a governing unit of China Building Waterproof Association, a vice chairman unit of Professional Committee of China Modified Plastic Association, an enterprise with Triple A credibility in China Plastic Association, not only assists the development of the relevant industries, but also upholds the conception of sustainable development by successive technological innovation. Upass so far has acquired over 100 of intellectual property rights. |
1. Taicang Production Plant:
2. Chenzhou Production Plant:
Certificates:
Why Upass:
Imported film blowing machine(From Germany):
Imported laminated machine(From Italy):
QC Department:
