Product Details:
|
Product Name: | Transparent PET Silicone Coated Release Liner | Material: | PET |
---|---|---|---|
Thickness: | 0.012-0.15mm | Width: | 100-2000mm |
Application: | Used For Waterproofing Membranes, Adhesive Tapes,etc. | Color: | Transparent, White, Gray, Etc. |
Performance: | Single Or Double Side Silicone Coated | Process: | Extrusion Casting |
High Light: | 0.012mm Silicone Coated PET Release Film,0.15mm Silicone Coated PET Release Film,0.012mm hdpe liner |
PET release film is also called PET silicone oil film. A layer of silicone oil is applied on
the surface of the PET film to reduce the adhesion of the PET film surface and achieve
the release effect.
Can be divided into single-sided release film and double-sided release film.
According to the release force, it can be divided into a light release film, a medium release
film, and a heavy release film.
Our company is equipped with a quick slitting machine that can be divided and sliced
according to customer specifications.
Features:
► High temperature resistance, up to 180℃
► Easy peel off when remove the release film
► High residual adhesiveness rate(≥90%) to prevent the influence of
silicon transfer on products
► Make products' surface more flat
Applications:
♦ Used for self-adhesive waterproof membranes and other waterproof materials,
adhesive tapes
♦ Used for cables production, packaging materials
♦ Used for cast materials, electronic applications, ceramic capacitors, window materials.
printing, electronic, advertisements
Phameter:
Products Name | PET release film | Spec. | 0.023mm*1000mm | ||
Detection Methed | Q/TPXP 1-2013 | Date | 2020.9.26 | ||
NO. | Item | Factory Requirement | Detection Value | Individual Determination | |
1 | Appearance | No bubbles, no stains, no damage, no impurities | Qualified | Qualified | |
2 | Spec. | Width | 1000±5mm | 1001 | Qualified |
Thickness | 0.023±0.005mm | 0.023 | Qualified | ||
3 |
Max.F (N/50mm) |
TD (CD) |
≥150 | 192 | Qualified |
MD | ≥150 | 156 | Qualified | ||
4 |
Elongation (%) |
TD (CD) |
≥40 | 87 | Qualified |
MD | ≥40 | 56 | Qualified | ||
5 | Tensile Strength(Mpa) |
TD (CD) |
≥30 | 124 | Qualified |
MD | ≥30 | 108 | Qualified | ||
6 | Subsequent Adhesion | % | ≥90 | 92 | Qualified |
Detection | Qualified |
