Product Details:
Place of Origin: China
Brand Name: Upass
Certification: CE, ROHS
Model Number: Cross Laminated Film
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Bubble Wrap & Wooden Pallet
Delivery Time: 15days
Payment Terms: T/T,L/C
Supply Ability: 200,000㎡~300,000㎡

Synthetic RoofiNg Underlayments Application Cross Laminated Film

Description
Product Name: Synthetic Roofing Underlayments Application Cross Laminated Film Material: HDPE
Production Process: Cross Laminated Performance: Anti-slip
Thickness: 0.09-0.26 Width: 100-1250mm
Color: Black, Grey, Blue, Green, Etc. Application: Underlayment, Waterproofing Membrane
Printing: Can Be Customizable Sample: Available
Highlight:

Underlayments Cross Laminated Film

,

Synthetic Roofing Cross Laminated Film

,

Anti Slip Cross Laminated Film

    Synthetic Roofing Underlayments Application Cross Laminated Film


Description:

It is made of HDPE Film as the carrier which
through multi-layer co-extrusion blow molding

into embryos, and then by multiple pull Stretching, then rotary cutting into a film substrate

at vertical distribution of 45 °, finally through cross-compositing by lamination machine.



Due to its cross-stacking structure is different from ordinary single-layer or multi-layer film,

it has the thermal stability, dimensional stability, two-way tear resistance, two-way uniform

tension and high elongation which are not available in traditional films. Make it the ideal

surface film for underlayment and waterproofing membranes.




Parameter:

NO. Item Performance
    SDM-30 SDM-60
1 Tensile Property Tensile Strength/Mpa ≥ 30 50
    MaxF/(N/50mm) ≥ 200 300
    Elongation as MaxF/% ≥ 200
    Elongation at break/% ≥ 250
2 Sample number of no broken tested by free-falling dart method ≥ 8
3 Tear Strength(Nail Shank)/N ≥ 60
4 Angle Tear Strength/N ≥ 25
5 Thermal Stability 120 ℃,10min, No bulb, No deformation
6 Cryogenic Flexibility ℃

-35℃,

No fissure, No delamination

7 Thermal Ageing Appearance No bulb, No deformation
    Subsequent MaxF/% ≥ 80
    Elongation at MaxF/% ≥ 200
    Elongation at break/% ≥ 200
8 Artificial Weathering Appearance No bulb, No deformation
    Subsequent MaxF/% ≥ 70
    Elongation at MaxF/% ≥ 180
    Elongation at break/% ≥ 180



Advantages:

  • Excellent dimensional stability.
  • Two-way tear resistance.
  • Performance against UV radiation.
  • High strength and high elongation performance.
  • Unique puncture resistance.
  •  Anti-slip function.


Application:


1. Surface material for slope roof underlayment;

2. Waterproofing membranes;

3. Labels & Tages;

4. Packaging materials.
