Product Details:
|
| Product Name: | Flame Resistance Printing Label Application Cross Laminated Film | Material: | HDPE |
|---|---|---|---|
| Production Process: | Cross Laminated | Performance: | Flame Resistance |
| Thickness: | 0.09-0.265mm | Width: | 100-1100mm |
| Color: | White | Application: | Label Printing |
| Printing: | Can Be Customizable | Sample: | Available |
| High Light: | Cross Laminated Hdpe Plastic Film,Printing Label Laminated Hdpe Film,Flame Resistant Laminated Hdpe Film |
||
Flame Resistance Printing Label Application Cross Laminated Film
Description:
It is multi-layers laminated film with high strength property, made via three layers
co-extrusion film blown process and special stretching technology. The inner crossed
structure differs from traditional films with one layer or many layers, possesses both
thermal stability and dimensional stability, good bidirectional tear resistance & high tensile
strength, as well as high elongation at bi-direction.
It is used for the markets of construction waterproofing, special packaging, label,etc.
Parameter:
| NO. | Item | Performance | ||
| SDM-30 | SDM-60 | |||
| 1 | Tensile Property | Tensile Strength/Mpa ≥ | 30 | 50 |
| MaxF/(N/50mm) ≥ | 200 | 300 | ||
| Elongation as MaxF/% ≥ | 200 | |||
| Elongation at break/% ≥ | 250 | |||
| 2 | Sample number of no broken tested by free-falling dart method ≥ | 8 | ||
| 3 | Tear Strength(Nail Shank)/N ≥ | 60 | ||
| 4 | Angle Tear Strength/N ≥ | 25 | ||
| 5 | Thermal Stability | 120 ℃,10min, No bulb, No deformation | ||
| 6 | Cryogenic Flexibility ℃ |
-35℃, No fissure, No delamination |
||
| 7 | Thermal Ageing | Appearance | No bulb, No deformation | |
| Subsequent MaxF/% ≥ | 80 | |||
| Elongation at MaxF/% ≥ | 200 | |||
| Elongation at break/% ≥ | 200 | |||
| 8 | Artificial Weathering | Appearance | No bulb, No deformation | |
| Subsequent MaxF/% ≥ | 70 | |||
| Elongation at MaxF/% ≥ | 180 | |||
| Elongation at break/% ≥ | 180 | |||
Advantages:
|
Flame Resistance |
| Outdoor Durability |
| TEAR RESISTANCE |
| CHEMICAL RESISTANCE |
| PUNCTURE RESISTANCE |
| HIGH STRENGTH |
| TEAR PROPAGATION RESISTANCE |
| HIGH ELONGATION |
Application:
1. Hanging IV Labels
2. Air Bag Covers
3. EKG Labels (electrocardiogram)
4. RFID (radio frequency identification)
5. Law Labels
6. Strength Tape
