90um HDPE Film

90um HDPE Film
90um HDPE Film

Large Image :  90um HDPE Film

Product Details:
Place of Origin: China
Brand Name: Upass
Certification: CE, ROHS
Model Number: Cross Laminated Film
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Bubble Wrap & Wooden Pallet
Delivery Time: 15days
Payment Terms: T/T,L/C
Supply Ability: 200,000㎡~300,000㎡

90um HDPE Film

Product Name: High Strength Thermal Dimensional Stability Cross Laminated Film Material: HDPE
Production Process: Cross Laminated Performance: Anti-slip
Thickness: 0.09-0.26 Width: 100-1250mm
Color: Black, Grey, Blue, Green, Etc. Application: Underlayment, Waterproofing Membrane
Printing: Can Be Customizable Sample: Available
High Light:

90um HDPE Film


0.26mm HDPE Film


0.09mm hdpe film roll


High Strength Thermal Dimensional Stability Cross Laminated Film




It is a high-strength multi-layer composite film,It is made of HDPE as the base material,

adding plasticizer, plasticizer, stabilizer, antioxidant, UV absorber, toughener and other

additives through multi-layer co-extrusion blow molding into embryos, and then by multiple

pull Stretching, then rotary cutting into a film substrate with a horizontal and vertical distribution of 45 °, and finally through cross-compositing. Due to its cross-stacking structure is different from ordinary single-layer or multi-layer film, it has the thermal stability, dimensional stability, two-way tear resistance, two-way uniform tension and high elongation which are not available in traditional films.

90um HDPE Film 0




NO. Item Performance
    SDM-30 SDM-60
1 Tensile Property Tensile Strength/Mpa ≥ 30 50
    MaxF/(N/50mm) ≥ 200 300
    Elongation as MaxF/% ≥ 200
    Elongation at break/% ≥ 250
2 Sample number of no broken tested by free-falling dart method ≥ 8
3 Tear Strength(Nail Shank)/N ≥ 60
4 Angle Tear Strength/N ≥ 25
5 Thermal Stability 120 ℃,10min, No bulb, No deformation
6 Cryogenic Flexibility ℃


No fissure, No delamination

7 Thermal Ageing Appearance No bulb, No deformation
    Subsequent MaxF/% ≥ 80
    Elongation at MaxF/% ≥ 200
    Elongation at break/% ≥ 200
8 Artificial Weathering Appearance No bulb, No deformation
    Subsequent MaxF/% ≥ 70
    Elongation at MaxF/% ≥ 180
    Elongation at break/% ≥ 180




When conditions demand high-performance packaging, Cross Laminated Strength Film

is your solution. Fungicides, pesticides, toilet bowl drop-ins, and pool chemicals can be

packaged in confidence, with proven child-resistance, when you use Cross Laminated

Strength Film. High-performance packages made with Cross Laminated Strength Film

provide high burst strength, unbeatable tear-resistance, superior moisture and chemical

resistance, as well as outstanding printability.

Whether you’re looking for a water resistant barrier, flashing tape, air barrier or other waterproofing products, you are sure to find these all built with cross laminated film.

Cross laminated film is puncture and weather resistant, has thermal dimensional stability and cold temperature resistance. Our cross-laminated process provides unbeaten mechanical performance and properties. We're constantly learning how to better create long-lasting foundations that can withstand numerous different situations and landscapes.




► Puncture Resistant

► High Thermal Stability: The ability to be used in any climate because of cross laminated

film's ability to withstand temperatures ranging from -30°-80°C. Provides a wide

temperature filling range, making cross laminated film the ideal material to pack explosive

gels, hot filled emulsions, and surface material of CONSTRUCTIO WATERPROOFING and

flashing tapes.

► Barrier against chemical migration

► Waterproof and Chemical Resistant: Barrier against water and moisture. The closed tructure (non porous, high barrier) of cross laminated film creates the ideal material in which your explosives are securely packed.

UV Stability for typical job site exposure

► High strength film allows roof underlayment to bridge gaps in sheathing and is resistant to damage from incidental movement and settling of the roof




A cross-laminated polyolefin that is taken to new levels of performance.

After countless iterations in our lab, we created a film that features outstanding strength,

a heightened spectrum of resistances in many categories, and much more. In fact,

you have probably already used a tag, label, or package made with award winning

Cross Laminated Film, as it can be found in electrical cord labels,

pilfer-resistant flexible packaging, pool chemical packaging,

and construction waterproofing membranes.



          90um HDPE Film 1




90um HDPE Film 2




90um HDPE Film 3




Q1: Are you trading company or manufacturer ?

A1: We are manufacturer.


Q2: Do you provide samples ? is it free or extra ?

A2: Yes, we could offer A4 sample for free charge but if you need in roll,

we can offer 100-200m/roll for free, but shipping cost need you to paid.


Q3: How long is your delivery time?

A3: Depends on your quantity. Generally it is about 30 days for 20GP container.


Q4: How to pay for your goods?

A4: By L/C, by T/T (30% deposit before production, 70% balance before loading).


Packaging and Shipment:


90um HDPE Film 4

90um HDPE Film 5

90um HDPE Film 6
