Red MOPP Release Film 100x55cm Single Sided Silicone Coated

Large Image : Red MOPP Release Film 100x55cm Single Sided Silicone Coated

Product Details:

Place of Origin:	Shanghai, China
Brand Name:	upasschina
Model Number:	Single/Double Silicon MOPP Release Film

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

Red MOPP Release Film 100x55cm Single Sided Silicone Coated

Description

Material:	MOPP/PP	Color:	White/Blue/Red/Sky Blue
Surface Treatment:	Single/Double Sided Corona Treatment	Surface Finish:	Single/Double Side Silicone Coated
Temperature Resistance:	130 ~ 150℃	Subsequent Adhesion Rate:	≥ 85%
Hardness:	Soft	Processing Method:	Co-extrusion Flow Extension
Transparency:	Translucent	Thickness Range:	0.04-0.12 Mm
Width Range:	20-1200 Mm	Sleeve Diameter:	76mm / 152mm
MD Tensile Strength:	≥300 Mpa	MD Elongation@Break:	≤50%
Peeling Force:	4-8;10~15;20~30 Gf/25mm
Highlight:	Red MOPP release film , Single sided silicone coated film , MOPP film 100x55cm

High Tensile Strength Rubber Adhesive Red Single Sided Mopp Film Strapping Tape

Single/Double Silicon MOPP Release Film

Material: PP
Type: Release Film
Application: Used as release materials for butyl tapes, acrylic tapes and foam tapes.

Special Performance

Temperature resistance: 130-150℃
Subsequent adhesion rate ≥ 85%
Hardness: soft
Processing: Co-extrusion flow extension
Transparency: Translucent

Product Specifications

Color: Transparent, milky white, sky blue, dark blue, red, etc
Thickness: 0.04-0.12mm
Width: 20-1200mm
Sleeve diameter: Inner diameter 76mm/152mm
Packaging: Tray
Capacity: 550T/month

Product Introduction

MOPP release film is a commonly used release material, widely used in adhesive tapes and self-adhesive products. It is made by single-sided or double-sided silicone oil coating based on the MOPP substrate. MOPP represents a Monoaxially Oriented Polypropylene Film, made by stretching the polypropylene film in a longitudinal and unidirectional direction, which provides high tensile strength, good mechanical properties and heat resistance.

Main Features

Good temperature resistance up to 150℃
High tensile strength (mechanical direction)
Soft properties with good adhesion performance
Excellent separation performance for easy peeling

Application

Performance Index

S.N.	Item	Unit	Performance Index
1	Appearance	/	Smooth film surface, No bubbles, no wrinkles, or no layering
2	Thickness	mm	0.06-0.10
3	Width	mm	20-1200
4	MD Tensile Strength	Mpa	≥300
5	MD Elongation@Break	%	≤50
6	Peeling Force	gf/25mm	4-8;10~15;20~30
7	Subsequent Adhesion Rate	%	≥85
