Product Details:
|
| Application: | Release Liner For Tapes, Bitumen Membranes | Main Features: | Embossed Treatment |
|---|---|---|---|
| Color: | Grey, Black, White, Green, Blue Ect | Material: | HDPE |
| Product Name: | Embossed Silicone Coated PE Thermal Release Film For Membranes And Tapes | Thickness: | 0.035-0.2mm |
| Curing Type: | Thermal Curing | Silicone: | Solvent |
| High Light: | HDPE Embossed Thermal Release Film,bitumen membranes Thermal Release Film,HDPE PE pet laminated film |
||
A release liner is a pleastic release film which made of PE, PP or PET film as carrier, silicon coated on either one or two-sided releases options.
The film is uniform coated and very smooth and clean without wrinkles/tears/granules/bubbles/pinholes or other defects. This highly conformable product bonds well to most surfaces over a wide range of temperatures and release film is heavily used in consumer products worldwide.
Embossed Release Liner as a release material. Its surface can be coating of ultra-thin layer of silicon from the type of material. The products are widely used in protective film, self-adhesive products, foam tape, die-cutting pressing, demoulding and other industries. It plays a very good isolation and protection role.
Advantages:
1.Easy peel off when remove the release film.
2.High residual adhesiveness rate(≥70%) to prevent the influence of silicon transfer on products.
3.Environmental Production technology of solvent and solvent-free products.
4.Environmentally Friendly. Can be recycling.
5.We have rich experience in product research and development to meet the various needs of customers.
| Product Name | Embossed Release Film | Spec. | 0.04*1030mm | ||
| Test Method | Q/320585-2019 | Date | 2022-8-25 | ||
| No. |
Item |
Factory Requirement |
Detection Value |
Individual Determination |
|
| 1 |
Appearance |
No bubbles, no stains, no damage, no impurities |
Qualified |
Qualified |
|
| 2 | Weight(g/m²) | 38±2 | 38.6 | Qualified | |
| 3 | Spec.(mm) | Width | 1030±5mm | 1032 | Qualified |
| Thickness | 0.04±0.005mm | 0.041 | Qualified | ||
| 4 | Max.F(N/50mm) | MD | ≥30 | 42 | Qualified |
| TD | ≥30 | 54 | Qualified | ||
| 5 | Elongation(%) | MD | ≥150 | 577 | Qualified |
| TD | ≥200 | 452 | Qualified | ||
| 6 | Release Force (gf/25mm) | 5-15 | 11.58 | Qualified | |
| 7 |
Subsequent Adhesion (%) |
≥75 | 80 | Qualified | |
