Product Details:
|
| Product Name: | Puncture Resistance High Strength Laminated Packaging Film | Material: | HDPE |
|---|---|---|---|
| Production Process: | Cross Laminated | Performance: | Puncture Resistance |
| Thickness: | 0.09-0.26 | Width: | 100-1250mm |
| Color: | White | Application: | Label Material, Packing Film |
| Printing: | Can Be Customizable | Sample: | Available |
| High Light: | 90um HDPE Film Roll,0.09mm HDPE Film Roll,0.09mm hdpe plastic sheet roll |
||
Puncture Resistance High Strength Laminated Packaging Film
Description:
It is a high-strength multi-layer composite film,It is made of HDPE as the base material,
adding plasticizer, plasticizer, stabilizer, antioxidant, UV absorber, toughener and other
additives through multi-layer co-extrusion blow molding into embryos, and then by multiple
pull Stretching, then rotary cutting into a film substrate with a horizontal and vertical
distribution of 45 °, and finally through cross-compositing. Due to its cross-stacking structure
is different from ordinary single-layer or multi-layer film, it has the thermal stability,
dimensional stability, two-way tear resistance, two-way uniform tension and high elongation
which are not available in traditional films.
| It is a high-strength multi-layer composite film,It is made of HDPE as the base material, adding plasticizer, plasticizer, stabilizer, antioxidant, UV absorber, toughener and other additives through multi-layer co-extrusion blow molding into embryos, and then by multiple pull Stretching, then rotary cutting into a film substrate with a horizontal and vertical distribution of 45 °, and finally through cross-compositing. Due to its cross-stacking structure is different from ordinary single-layer or multi-layer film, it has the thermal stability, dimensional stability, two-way tear resistance, two-way uniform tension and high elongation which are not available in traditional films. |
| Laminated film is an extremely versatile, high-performance product line that resists tearing, puncturing, and weathering. Our proprietary, cross-lamination manufacturing process provides considerably tighter gauge control than competitive spun bonded, smoother printing surfaces, and ease in converting. It is so strong that it will not tear, even when nicked, and withstands cold temperature. UV stabilized, the grades hold up well during outdoor exposure and provides superior moisture and chemical resistance making it ideal for engine tags as well as cruise and freight tags. |
Phameter:
| NO. | Item | Performance | ||
| SDM-30 | SDM-60 | |||
| 1 | Tensile Property | Tensile Strength/Mpa ≥ | 30 | 50 |
| MaxF/(N/50mm) ≥ | 200 | 300 | ||
| Elongation as MaxF/% ≥ | 200 | |||
| Elongation at break/% ≥ | 250 | |||
| 2 | Sample number of no broken tested by free-falling dart method ≥ | 8 | ||
| 3 | Tear Strength(Nail Shank)/N ≥ | 60 | ||
| 4 | Angle Tear Strength/N ≥ | 25 | ||
| 5 | Thermal Stability | 120 ℃,10min, No bulb, No deformation | ||
| 6 | Cryogenic Flexibility ℃ |
-35℃, No fissure, No delamination |
||
| 7 | Thermal Ageing | Appearance | No bulb, No deformation | |
| Subsequent MaxF/% ≥ | 80 | |||
| Elongation at MaxF/% ≥ | 200 | |||
| Elongation at break/% ≥ | 200 | |||
| 8 | Artificial Weathering | Appearance | No bulb, No deformation | |
| Subsequent MaxF/% ≥ | 70 | |||
| Elongation at MaxF/% ≥ | 180 | |||
| Elongation at break/% ≥ | 180 |
|||
Advantages:
► Corona treated for optimal results when flexo, offset, or screen printed, can also be
thermal transfer printed (ANSI A Scans)
► Outdoor Durability: UV stabilized for improved weather resistance and performance in
harsh environments
► Performance in temperatures from -35°C-75°C
► Good ink adhesion: non-smearing
► Chemical and Oil Resistance
► Pre-printed or print-on-demand
► Excellent Staple Pullout Resistance
Application:
|
It is special design for packing materials, such as chemical packaging, cotton packaging and emulsion explosives and so on. |
