Product Details:
|
| Product Name: | Embossed Silicone Coated HDPE Release Film | Material: | High Density Polyethylene (HDPE) |
|---|---|---|---|
| Thickness: | 0.03-0.15mm | Width: | 100-2000mm |
| Application: | Used For Waterproofing Membranes, Adhesive Tapes,etc. | Color: | Black, Grey, White, Blue, Green, Etc. |
| Performance: | Embossed | Process: | Three-layers Blowing |
| High Light: | 30um High Density Polyethylene Film,0.03mm High Density Polyethylene Film,0.03mm embossed polyethylene film |
||
HDPE release liner refers to the film with separative film on the surface.
HDPE release film does not have viscidity or slight viscidity contact with specific material under the limited conditions. Normally in order to increase the release force of the film, it does corona treatment to the film and coated with silicone, to make it act out the light and stable release force to different organic pressure glue. According to different release film , the release force is different, the viscidity of release product glue is different , to adjust the release force, to make it have the light and stable release force during peeling. There are thermal curing and UV curing for silicone coating due to different release force requirements.
The type of embossing:
Type 1:
Type 2:
1.Easy peel off when remove the release film.
2.High residual adhesiveness rate(≥70%) to prevent the influence of silicon transfer on products.
3.Environmental Production technology of solvent and solvent-free products.
4.Environmentally Friendly. Can be recycling.
Parameter:
| Products Name | HDPE film | Spec. | 0.1mm*920mm | ||
| Detection Methed | Q/TPXP 1-2013 | Date | 2020.7.2 | ||
| NO. | Item | Factory Requirement | Detection Value | Detection | |
| 1 | Appearance | No bubbles, no stains, no damage, no impurities | Qualified | Qualified | |
| 2 | Spec. | Width | 920±10mm | 922 | Qualified |
| Thickness | 0.1±0.005mm | 0.102 | Qualified | ||
| 3 |
Max.F (N/50mm) |
TD (CD) |
≥150 | 204 | Qualified |
| MD | ≥150 | 212 | Qualified | ||
| 4 |
Elongation (%) |
TD (CD) |
≥200 | 1155 | Qualified |
| MD | ≥200 | 968 | Qualified | ||
| 5 | Tensile Strength |
TD (CD) |
≥18 | 21 | Qualified |
| MD | ≥22 | 25 | Qualified | ||
