Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes

Certification
China Upass Material Technology (Shanghai) Co.,Ltd. certification
China Upass Material Technology (Shanghai) Co.,Ltd. certification
I'm Online Chat Now

Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes

Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes
Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes
Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes

Large Image :  Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes

Product Details:
Place of Origin: China
Brand Name: Upass
Certification: CE, ROHS
Model Number: Cross Laminated Film
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Bubble Wrap & Wooden Pallet
Delivery Time: 15days
Payment Terms: T/T,L/C
Supply Ability: 200,000㎡~300,000㎡

Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes

Description
Product Name: Slip Resistance Underlayment Application Cross Laminated Film Material: HDPE
Production Process: Cross Laminated Performance: Anti-slip
Thickness: 0.1-0.26 Width: 100-1100mm
Color: Black, Grey, Blue, Green, Etc. Application: Underlayment, Waterproofing Membrane
Printing: Can Be Customizable Sample: Available
High Light:

High Strength HDPE Cross Laminated Film

,

Multi Layer HDPE Film

,

Composite Cross Laminated Film

Slip Resistance Underlayment Application Cross Laminated Film


Description:

It is a high-strength multi-layer laminated film, Use HDPE Film as the base material, through

multi-layer co-extrusion blow molding into embryos, and then by multiple pull Stretching,

then rotary cutting into a film substrate with a horizontal and vertical distribution of 45 °,

and finally through cross-laminating.

Due to its cross-stacking structure is different from ordinary single-layer or multi-layer film,

it has the thermal stability, dimensional stability, two-way tear resistance, two-way uniform

tension, high strength and high elongation which are not available in traditional films.



The surface is slip resistance after special treatment, it is the idea material for slope

underlayment membranes, butyl tapes and other products.


Advantages:

  • Excellent dimensional stability.
  • Two-way tear resistance.
  • Performance against UV radiation.
  • High strength and high elongation performance.
  • Excellent resistance to high and low temperature.
  • Unique puncture resistance, self-healing and continuous tear resistance
  • and excellent nail water tightness.
  • Anti-Slip

Parameter:


NO. Item Performance
    SDM-30 SDM-60
1 Tensile Property Tensile Strength/Mpa ≥ 30 50
    MaxF/(N/50mm) ≥ 200 300
    Elongation as MaxF/% ≥ 200
    Elongation at break/% ≥ 250
2 Sample number of no broken tested by free-falling dart method ≥ 8
3 Tear Strength(Nail Shank)/N ≥ 60
4 Angle Tear Strength/N ≥ 25
5 Thermal Stability 120 ℃,10min, No bulb, No deformation
6 Cryogenic Flexibility ℃

-35℃,

No fissure, No delamination

7 Thermal Ageing Appearance No bulb, No deformation
    Subsequent MaxF/% ≥ 80
    Elongation at MaxF/% ≥ 200
    Elongation at break/% ≥ 200
8 Artificial Weathering Appearance No bulb, No deformation
    Subsequent MaxF/% ≥ 70
    Elongation at MaxF/% ≥ 180
    Elongation at break/% ≥ 180



Application:



1. For Underlayment Waterproof Membranes

2. For Butyl Tapes



Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes 0



About Upass:



Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes 1



Anti Slip High Strength HDPE Cross Laminated Film For Waterproof Membranes 2



Upass, founded in 2008, is headquartered in New Materials Industrial Park, Qingpu District, Shanghai, and has two production bases in Taicang, Jiangsu and Chenzhou, Hunan. Now as a governing unit of China Building Waterproof Association, a vice chairman unit of Professional Committee of China Modified Plastic Association, an enterprise with Triple A credibility in China Plastic Association, not only assists the development of the relevant industries, but also upholds the conception of sustainable development by successive technological innovation. Upass so far has acquired over 100 of intellectual property rights.
UPASS will spare no effort in strengthening and improving the production, sales networks, service system to return the trust and support of customers, and look forward to working with you in a win-win future.
